FEATURES:

• Adjustable Volume Control
• Replaceable Tip
• LED Signal Indicator
• Test Telephone Port
• Headset Jack
• ED Flashlight
• Continuity & Polarity LED
• External Warble Select
• RJ11 & RJ45 Socket
• Lanyard
• Short Circuit LED/Beeper
• Single/Dual Line Modular LED
• Alligator/ABN Connector Clips

SPECIFICATIONS:

• 5 Digit UPC: 49990
• Talk Battery (into 600?): 4.6 VDC
• Output Power (into 600?): +10 dBm
• Resistive Short Visual Indication: <10 k?
• Resistive Short Audio Indication:<200?
• Output Frequency (nominal) Alternating-890/960 Hz, Warbling-Slow: 1.3 Hz/Fast: 6 Hz
• Voltage Protection
• (into 600?): 150 VDC
• Battery: 9 VDC (NEDA 1604, JIS 006P, or IEC 6LF61)
• Battery Life: >50 hours
• Height: 57 mm (2.25”)
• Width: 64 mm (2.5”)
• Depth: 32 mm (1.25”)
• Weight (max): 128 g (4.5 oz.)
• Operating Temperature: 0 ° C to 50 ° C (32 ° F to 122 ° F)
• Storage Temperature: -50 ° C to 75 ° C (-58 ° F to 167 ° F)
